Vertical bagging machine YUKON

VFFSPLC-controlled

 Vertical form, fill and seal machine, model YUKON PE with centre folded film controlled by PLC Siemens. General technical characteristics: • Main Structure made of varnished steel; • Electrical cabinet is fixed to the machine; • Pneumatic reel-holder shaft; • End of film automatic detection system with automatic machine pause when the film-reel is over; • Motorized film-pulling unit; • Film-unwind process is carried out by a toothed belt coated in Linatex; • N.1 Loading station fully respecting the ruling safety norms; • Pneumatic unit for horizontal sealing and cutting processes, with sealing band and knife; • Pneumatic unit for vertical sealing and cutting processes, composed of a hot bar fit to an adjustable sliding block; • Bag length measuring system: Encoder • Exit conveyor belt, which holds and leads the already made bags outwards. It can be adjusted (up/downwards) according to the vertical size of the bag; • Film pulling device for wasted film; • Max. bag length: 500mm; • Max. empty bag width: 480 mm; • Max film reel width: 570mm. • PLC Siemens control system; • CE Certification. • Power Supply: 380V-50HZ-3 phase+N-Ground.
