Ethernet interface

This interface provides 8 user inputs and 8 user outputs. These can be controlled / monitored by Ethernet commands or can be used to interact with the Sequencer to make the power supply act like a Power PLC. Features 8 inputs 8 Open Collector outputs Programmable via Ethernet or sequences Isolated from the output voltage, working voltage 1000 VDC Floating with respect to earth Functionalities Hardware triggering of sequences Interaction with other equipment Stand-alone automation For SM3300 and SM15K series only, multiple INT MOD DIG per unit allowed Installation in all slots possible Combination with other interfaces for SM3300 or SM15K series possible Easy to plug in by user on site Specifications 8 inputs Logic high: 2 - 30 V 8 Open Drain outputs: 0 - 30 V, max. 200 mA Insulation programming connector - internal circuits: 1000 VDC Operating temperature: -20 to +50 ºC Standards Safety: EN 60950 / EN 61010 Dimensions and weight Width: 25 mm Height: 77 mm Depth: 77 mm Weight: 80 gr
