3-axis ultrasonic anemometer AEOLUS-3

IP67with analog outputRS-485

AEOLUS is our ultimate solution for precise wind monitoring in any environment. Specifically suitable for applications such as: •Wind farm monitoring •Automatic Weather Stations (AWS) •Buildings, constructions and bridges control •Ports, airports and heliports •Road and railway tunnels Beside the measurement of wind speed and direction, it provides U-V-W Cartesian components and Wind Gust values. With integrated heating, it prevents the whole detection area (sensors, arms and arms supports) from the accumulation of snow and ice formation, allowing accurate measurements in all environmental conditions. Moreover, the AISI 316 housing provides durability and protection, making it suitable for measurements in the toughest conditions. The anemometer integrates a barometric pressure sensor. Available outputs: •RS232, RS485 and RS422 isolated outputs, with NMEA, Modbus-RTU and ASCII proprietary protocols. •SDI-12 isolated output. •Three analog outputs, for wind speed and direction or for wind U-V-W cartesian components. The type of analog output depends on model. The anemometer satisfies the requirements of the following standards: •MIL-STD-810G Method 509.6 and EN ISO 9227:2017 (salt fog anti-corrosion test) •MIL-STD-810F Method 521.2 (anti-icing/freezing rain test) •EN 60068-2-6:2008 / IEC 60068-2-6:2007 (vibration resistance test) Supplied with PC software, for configuration and displaying of the real time measurements. All instrument sensors are factory-calibrated and do not require additional interventions of the user.
