Thermal evaporator TC series

laboratoryelectriclow temperature

Compact Evaporators for Tunnel Freezers Exceptionally compact for tunnels with reduced dimensions. Hinged front cover for easy access to resistors and for cleaning the finned coil. Far less blockage in the fin assembly, due to spacing of 8 mm, permitting application at lower temperatures and with high air humidity. Stainless steel housing optional. For the size of the packaging, add the following measurements to the equipment dimensions: X + 50mm, Y + 90mm and Z + 20mm TC = without electric defrost TCD = with electric defrost TCI = with installation for electric defrost TCC = with housing in stainless steel Voltage of the aforementioned fans is 3-phase 380V. To convert to 3-phase 220V multiply the value by 1.7. The above flows are stated for 60Hz, however the motorized fans also operate at 50 Hz, while in this case the flow drops by approximately 13% and the capacity by approximately 7%. Note: for application in other evaporation ranges, consult the Delta Frio Application Engineering department.
