Oil hose MSB21 seriessynthetic rubberNBRabrasion-resistant
Add to favorites
Compare this product
Characteristics
- Use
- for oil
- Material
- synthetic rubber, NBR
- Other characteristics
- abrasion-resistant, oil-resistant, weather-resistant, braided, fabric-braided
- Inner diameter
Max.: 25 mm
(0.984 in)Min.: 6.3 mm
(0.248 in)- Outer diameter
Max.: 34.5 mm
(1.358 in)Min.: 13 mm
(0.512 in)- Pressure
20 bar, 21 bar, 24 bar, 28 bar
(290.075 psi, 304.579 psi, 348.091 psi, 406.106 psi)- Temperature
Max.: 100 °C
(212 °F)Min.: -40 °C
(-40 °F)
Description
This Disca-made apparatus possesses an operating temperature range of -40 to 100 degrees Celsius. Its internal tube has been manufactured out of specialized NBR rubber materials tolerant to hydraulic oils, while its external housing has been made out of synthetic rubber retardant to weather, abrasion, and oil elements. Its structure has been fortified with a single textile braid.
