Chemical pump LD
brushless DCself-priminggear

chemical pump
chemical pump
chemical pump
chemical pump
chemical pump
chemical pump
chemical pump
chemical pump
chemical pump
chemical pump
Add to favorites
Compare this product


Characteristics

Fluid
for chemicals
Operation
brushless DC
Priming
self-priming
Technology
gear
Mobility
stationary
Domain
chemical, medical
Applications
transfer, cooling
Material
stainless steel, EPDM
Fluid specification
for aggressive media
Protection level
chemical-resistant, maintenance-free
Other characteristics
compact, heavy-duty, low-noise, OEM, low-pressure, heavy-duty, custom
Flow

Min.: 0.05 l/min
(0.01321 us gal/min)

Max.: 2.5 l/min
(0.66043 us gal/min)

Pressure

4 bar, 6 bar, 15 bar
(58.015 psi, 87.023 psi, 217.557 psi)

Fluid temperature

Min.: 0 °C
(32 °F)

Max.: 95 °C
(203 °F)

Description

Silencer LD extends the successful Silencer series gear pump to light duty applications requiring a more compact size. Full Description Silencer LD precision gear pump extends the successful Silencer series to applications requiring a very compact size. This pump uses the same inexpensive, maintenance-free motor system while taking advantage of advanced pump manufacturing techniques to reduce size while still providing the life that Silencer pumps are known for at pressures up to 4 bar. The 316L stainless steel casting allows for numerous port options at different orientations. Mounting holes are provided for easy integration into customer machines. Custom body designs can easily be provided for high volume OEM applications. Benefits Low Cost Not all applications require maximum pump capability. Silencer LD has been optimized to lower cost while still providing superior Diener quality and reliability. Long-life DPP pumps are all characterized by their robustness and performance. Wear and tear is at its lowest, and their smart designs ensure a sustainable reduction of operating costs. 100% Outgoing Testing Before any order is shipped, every pump undergoes strict and thorough testing in compliance to its specifications at our factory. We send comprehensive reports to our clients, which not only save them time but also money. Chemically Resistant Our pumps are made from materials that are resistant to a wide range of aggressive chemicals. This ensures that our pumps can operate reliably and precisely even in the most severe conditions.
