Metal pipe expansion joint MFProundflangeweld-on
Add to favorites
Compare this product
Characteristics
- Material
- metal
- Configuration
- round
- Installation system
- flange, weld-on, screw-in
- Applications
- for pipes, turbine
- Other characteristics
- custom
- Nominal diameter
Max.: 2,000 mm
(78.74 in)Min.: 15 mm
(0.59 in)- Pressure
64 bar
(928.2 psi)
Description
Custom model stainless steel angular expansion joint composed of one single- or multi-ply bellow with hinged system, for mounting with flanges up the pipeline.
Construction with hinged system for movement limitation. Available with optional inner sleeve for bellow's protection and improved stability. Couplings can be made out of various carbon-steel or stainless steel grades.
For detailed technical specifications on MFP expansion joints please check the following table and documents or contact us.
Features
stainless steel bellow
angular movement compensation
hinged system
fixed (weld-on) flanges
fully customizable item
Catalogs
No catalogs are available for this product.
See all of Dieter A. Roth GmbH‘s catalogs
