Complete development platform for intelligent, connected and secure embedded industrial products with a broad suite of tools and turnkey Linux software support
The kit includes:
Digi ConnectCore® MP133 development board with SOM
Console port cable
Dual-band wireless antenna
Power supply and accessories
Reference designs and online documentation
Features and benefits:
Industrial-grade, scalable, embedded SOM platform
Pre-certified dual-band Wi-Fi 5 (802.11ac) and Bluetooth® 5.2
Power management with hardware and software support
Digi SMTplus form factor (29 x 29 mm) for ultimate reliability
High level of pin compatibility with Digi ConnectCore 6UL SOMs
Built-in Digi TrustFence® device security, identity and privacy
Seamless cellular modem and Digi XBee® integration
Digi Embedded Yocto Linux support
Turnkey development services from Digi WDS
Development Board Features:
Gigabit Ethernet + 10/100 Mbit Ethernet
(2) USB Host, 1 x USB OTG
(2) CAN-FD
MicroSD card
PCIe minicard with SIM card holder
MikroE Click boards™ connector
Console over USB
Digi XBee (including Digi XBee Cellular support)
Audio (microphone and headphones)
User buttons and LEDs
