Video receiver XVID3D V3

analogfor surveyingindustrial

Diversity video receiver RXVID3V2 and video transmistter XOSD3B. Professional analog video system prepared for all types of applications FPV to work between 25-40Km (LOS) with antennas included in the kit or 100km if you use high gain parabolic antennas. Prepared for all types of vehicles: UAV, Drone, Helicopter, Cars, Boats, Robots, etc. The XOSD3B video transmitter is compatible with any autopilot that uses the Mavlink protocol: APM, Cube, pixhawk, etc. Control video system functions from any XLRS transmitter: Auxiliary servo control, camera selection, brightness level, page change, etc. You can choose several XVID3V2 video systems with the same frequency 1.2Ghz, 2.4Ghz, 5.8Ghz or in different frequencies to have a redundant video system 2.4Ghz-1.2Ghz, 1.2Ghz-5.8Ghz, 2.4Ghz-5.8Ghz. As a novelty in the RXVID3D V3 video receiver, now the video receiver modules for diversity mode can work individually, which means that a single frequency can be used in the two RX modules or each module in a different frequency to have a redundant system and working in diversity mode, with which the system will automatically select the RX with the highest signal. A new screen a little bigger than the previous one and with color to clearly show each data of the video system, (Video signal level, Video channel RX1, Video channel RX2, Video channel TX1, battery level, alarms…).
