Steel guardrail myMIX®

CHOICES AND MODULAR DESIGN Guardrails matching all our models of EXALT® and myMIX® railings. Base-plated or surface-mounted post to suit all configurations. EASY TO INSTALL Wall bracket. Angle management made possible due to the connection system and specially designed posts. STYLE AND FINISH Perfect matching with EXALT® and myMIX® barred railings and ALLIX ® gates. Modern design compatible with all architectural styles. Slot installation with invisible connections. SECURITY Compliance with guardrail standards: NF P01-012 and NF P01-013 (CSTB). Screws are inaccessible after installation. Reinforced post. CUSTOMISATION 6 standard colours: . 200 RAL colours. Matt and textured finishes. In accordance with the standard CE NF 13241 10 year Polyester guarantee Protect guarantee Dimensions 1040 mm Matching all our barred railings to ensure everything blends together perfectly on the site Collectifs d'habitation Housing complexes Lieux publics Public areas Sites tertiaires Service sector sites Sites industriels & logistiques Industrial & logistics sites Railings: 3 rails of 50 × 30mm Bar centre distance of 135mm Space between bars is a maximum of 110mm Post: 60 × 60mm square post Flat base-plated or surface-mounted Finish: Railings and posts in Sendzimir galvanised steel with polyester coating Connection accessories provided: stainless steel “U” + self-tapping screw + black polyester end cap
