Skate wheel guideway 90x180aluminumcompact
Add to favorites
Compare this product
Characteristics
- Technology
- skate wheel
- Other characteristics
- aluminum, compact
- Rail length
Min.: 0 mm
(0 in)Max.: 3,000 mm
(118.11 in)- Rail width
180 mm
(7.09 in)
Description
Product Description It is the most powerful model in the spot series. Because it is a double-rail structure which has a dynamic torque of this motion systems more preferred where is needed moment strength. The system long-lead ball screws can be achieved by integrating work faster. The system long-lead ball screws can be achieved by integrating work faster. Through linear rail and ball screw İt offers precise operation in automation and machine design.
Body; Aluminium (6063) 90x180 (Light) Profile
Speed; = 0.17 m / s
Drive; screw
Linear Rails; 20-Hsi
Linear Block; 20-Narrow
Screw; Q20-05 (Pitch)
Preservatives; Shield Seal and Bellow applications can be made according using area.
Cylindrical Nut; RSU-20-05
Sensitivity; 0.02 mM
Engine Option; Geared Motors Servo-Step
