Roller feeder RFS series

high-speed

A high-speed roller feeder is a type of feeding machine used in the metal stamping process. It works by using an eccentric disk attached to the punch output shaft to drive the feeding rollers and achieve precise feeding. The advantages of high-speed roller feeders include fast speed, high accuracy, good stability, and high cost-effectiveness. When choosing a high speed roller feeder, it is important to consider the scope of its application, as it is not suitable for all punches. For example, the width of the material being stamped must be within 700mm, the thickness of the material must be within 3.5mm, and the stamping feeding pitch must be within 300mm. The Seven Major Advantages of the High-speed Roller Feeder Machine in its Structure: 1.One-way Bearings (Safe, Wear-resistant): Embedded with hard alloy and paired with roller bearings, they have high wear resistance, stability, accuracy and long service life. The gears are heat-treated to HRC60° and then precision-ground, with high transmission accuracy. 2.Rollers (Light weight, High hardness): Adopting a hollow type, light weight and small rotational inertia, it can stop in real-time to ensure feeding accuracy. After heat treatment to HRC60° and hard chrome plating, it has high hardness, excellent wear resistance and long service life. 3.Disc Brakes (General Braking Devices): Adopting advanced clutches to make the two sides of the disc completely in contact, it has a long service life and good stability and accuracy.
