Hydraulic press

stampingblankingwelding

1. The power source is from several servo motors . The encoder connected to the crankshaft of the press transmit angle signals to the control system to achieve synchronous movement with the press . 2. It has a misfeed detection circuit to ensure the safety of the mold and machine . 3. The main frame adopts welding structure. Each axis is driven by precision balls screw rods, with high positioning accuracy . 4. The feeding system can adopt three in one feeder, swing feeder or double stack stacking rack . 5. Automatic production, strengthen operation safety, improve production capacity, stabilize product quality, and effectively reduce defect rate and cost . 6. Advanced motion controller and touch type interface control system are used to monitor the angle and abnormal state detection during operation . 7. Various stamping operation parameters can be input, modified and adjusted through the human-machine interface, which is easy to set and maintain . Zigzag circle blanking production line : Options when progress stamping line : 2in1 Straightener + Zigzag Feeder + Double sides lubricator + 3 axis Transfer + Hydraulic Cutter
