Durability testing machine RS-8432

automaticfor chair

This tester is made according to CNS requirement, this tester is to do the durability testing by simulating the stroller cross the barricade. The testing method is to put the infant model inside the stroller, raise the stroller to get the back wheels up 150mm from the ground, then press the handle down to get the front wheels up to 150mm from ground, and to do this action with the speed 15cycles/min. After 3000cycles continuous testing, to check the stroller if damage. The tester will automatically stop when reach the set testing cycles. Specification  Model: RS-8432  Max load: Max 50 pound  Stroke of testing: Go and back 120-150mm (stroke is adjustable by the screw stem)  Test speed: 15cycles/min±1cycle  Up and down adjustable range : Max 450mm (hand wheel adjusting)  Effective height: Max 600mm  Testing space: Single stroller  Counter: 0~999,999times ( can set )  Weight: 600Kg  Dimension: W1650xD1100xH1900mm  Power: AC220V 50Hz 3A or specified by user
