Electronic product drop tester RS-DP-04 series

Apply for repeating dropping (light dropping) testing of mobile phone, telephone receiver, interphone, MP3, CD, electronic dictionary, etc. To check if the products’ parts and function normal or not after many times light dropping. Model: RS-DP-04-1 (economic) RS-DP-04-2 (precise) Test amount: 1 pcs: 2 pcs Test load (max): 2 Kgf (max) Drop Height: 300mm (or specified) Test speed: 5~25 times/min Test cycle: 1~999999 times (cycle) Dimension (WxDxH): 420x370x850mm 850x370x850mm Weight: 25 Kg 80 Kg Air source: ≥0.5 Mpa Power supply: AC 220V 50 Hz 3A or specified by user Advantages • 1.All the testing conditions is inputted by touching screen directly. • 2.Adopt Japan SMC precise pneumatic component, durable using. • 3.Adopt Mitsubishi high quality LCD touching screen + PLC as program control.
