Bending tester RS-8116-6A

cable

It is suitable for bending resistance test on headphone cable.USB cable,multicore cable conductor,flat cable and signal line,etc.The test method is as follows:Firstly,clamp one end of the wire rod and fasten it to the rotation clamp. Then have it make a horizontal rotaion with hanging load to evaluate whether wire rod conduction is good after numerous test cycles. ification Model: RS-8116-6A System control: It adopts Japanese OMRONRtouch screen and MITSUBISHIRPLC,and each station works independently Impedance test module: It is equipped with impedance test module and color touch screen Drive: Six Japanese PanasonicRAC servo motor Reducer: Six Japanese ShimpoRAC servo motor Test speed: 1~60rpm±0.5rpm Test angle range: Commonly 0~±950 or 0~±1800,rotation angle of concentric jig is not limited The least angle display: 0.1 The cycles range: 1-999999 cycles Diameter of rotary disk: ￠210mm Weight: Each six of 100g,225g,300g,400g, Main unit dimension: W1780xD860xH1600mm Control box dimension: W720xD500xH1700mm Total weight: 555kg Power: AC 220V 50HZ 12A Features Each of which adopts Japanese PanasonicAC servo motor drive. They are positioned with high precision,with low noise and can be used for a long time, The test angle is±1°. Each station adopts Japanese SHIMPO planetary gear for slowing down with highly precise positioning.
