Die cutting machine JLA4 series
for aluminumfor plasticssheet metal

die cutting machine
die cutting machine
die cutting machine
die cutting machine
Add to favorites
Compare this product


Characteristics

Technology
die
Material
for aluminum, for plastics
Product handled
sheet metal
Other characteristics
alloy steel
X travel

Max.: 300 mm
(11.81 in)

Min.: 150 mm
(5.91 in)

Y travel

Max.: 200 mm
(7.87 in)

Min.: 100 mm
(3.94 in)

Maximum cutting height

400 mm, 450 mm, 500 mm, 600 mm, 700 mm
(15.7 in, 17.7 in, 19.7 in, 23.6 in, 27.6 in)

Laser power

3,750 W, 5,500 W

Overall length

900 mm, 980 mm, 1,250 mm, 1,340 mm
(35 in, 39 in, 49 in, 53 in)

Overall width

850 mm, 900 mm, 1,100 mm, 1,150 mm
(33 in, 35 in, 43 in, 45 in)

Height

2,105 mm, 2,155 mm, 2,270 mm, 2,550 mm, 2,750 mm
(83 in, 85 in, 89 in, 100 in, 108 in)

Weight

900 kg, 1,020 kg, 1,120 kg, 1,650 kg, 2,400 kg
(1,984.16 lb, 2,248.72 lb, 2,469.18 lb, 3,637.63 lb, 5,291.09 lb)

Description

1. High efficiency and energy saving: Adopt imported motor and control system, fast conversion of child and mother cylinder, fast empty running degree, high efficiency and energy saving. 2. Quality assurance: Four columns made of high strength alloy steel, hard chrome plated surface, good wear resistance. 3. Flexible operation: pressure, stroke and pressure time can be adjusted according to the pressing process requirements. 4. Safe and convenient: the machine is equipped with protective cover, anti-fall device, blowing chip removal device, LED working light and infrared ray Scope of application: 1. Applicable to all kinds of aluminum alloy, magnesium alloy die casting raw edge punching and shaping 2. It is widely used in die casting industry of aluminum magnesium alloy mobile phone products, automobile and motorcycle parts 2. Shaping and punching of metals or nonmetals.
