Female pin header L496XX-XXXXXdouble-rowstraight2.54 mm (0.100")
Add to favorites
Compare this product
Characteristics
- Type
- female
- Form
- double-row
- Other characteristics
- straight
- Pitch
- 2.54 mm (0.100")
Description
Part No: L496XX-XXXXX
Mating:L495XX-XXXXX
Packing:Tray
Delivery time:7~15 Day
UL:Yes
ROHS Compliant
Current Rating - 3.0AMP
Contact Resistance - 30mΩ Max
Withstand Voltage - 1000V AC/DC
Insulation Resistance - 1000mΩ
Operation Temperature - ﹣55℃ to +105℃
Contact Material - Brass
Contact Plating - Au And Sn over Ni
Fixing Material - Phosphor Bronze
Fixing Plating - Sn over Ni
Housing Material - PBT+30%GF(UL94V-0)
Cover Material - PBT+30%GF(UL94V-0)
