Proportional dosing unit DOSATec D45

waterfor the food industry

Dosing range: 0.03 – 8 % Pressure range: 0.5 – 5 bar, depending on the model Water flow rate: 100 – 4500 l/h Dosing feed rate: 0.033 – 360 l/h Dosing: proportional, e.g. a setting of 1% corresponds to a dosage of 1 :100 Average dosage tolerance: ± 10 % Reproducibility: ± 3 % (API675) Pressure loss: 0.2 – 2.3 bar How it works When connected to the water mains, the doser uses the water pressure as its driving force, which causes it to draw concentrate in, dose it at the required concentration and mix it with the drive water. The stock solution made in this way flows through the doser. The amount of product dosed is proportional to the water flow rate, even if there are fluctuations in the flow rate or water pressure. Areas of application Disinfection, cleaning, fertilisation, pest control, lubrication, pH/TH regulation, flocculation, car washes Environmental industry, hygiene, water treatment, food industry, car washes, metal processing, printing industry, horticulture
