Water jet washing machine COP-96-COMBO

sprayautomaticfor the food industry

The COP-96-COMBO is the ideal solution for cleaning irregular shaped machine parts, valves, tubes and other items that are difficult to clean with conventional spray manifolds due to masking. The unit can be used with side jets, end jets or a combination of both. Depending on the size and type, parts can be placed directly in the agitated ank or immersed in baskets fitted with handles. FEATURES • Rugged Stainless Steel Construction • 96" Long Wash Tank • NEMA 4X Control Panel • High Effi ciency Motor • Automatic Temperature Control • Steam or Electric Booster Heating • Multiple Turbulation Patterns • Portable With Castors • Adjustable Cycle Time • Side and End Jets • Tri-Clover Clamps for Ease of Cleaning • Optional Parts Baskets • One Year Warranty Program The COP-96Combo is designed to aid in the cleaning of fittings, machine parts, valves and tubes in a recirculating wash tank that provides continuous, turbulent, jet action. Versatility and cleaning effectiveness are provided by employing side jets, end jets, or a combination of botbby opening and closing valves in the supply manifolds. This controlled action is ideal for cleaning irregular shaped parts that fend to have surfaces that are difficult to reach with conventional spray patterns. Radius corners and the lack of any protrusions in the inside of the wash tank insures proper flow. The wash cycle is started by setting the wash timer and pressing the start button. Water temperature is maintained with your choice of live steam injection or electric maintenance heating.
