Dredge swivel bend

FEATURES of Dredge Swivel Bend and Swivel Elbow: Two elbows are connected together having standard flanges on both sides The main moving parts is connected together with the use of a bearing Both swivel elbows are made from thick cast steel The bearing of swivel bend is protected by steel cover The bearing is lubricated through a grease fitting The swivel bend pipes are made from smooth pipe surface inside and big pipe radius BENEFITS of Dredge Swivel Bend and Swivel Elbow: The swivel bend and swivel elbow are heavy duty design suitable for any material in the mining and dredging such as slurry, mud, sand, gravel, rocks and debris Highly flexible connection allowing the discharge pipe to move freely after connecting to the cutter Low flow restrictions and low pressure drop due to the smooth bend wall and small bearing connection OPTIONS of Dredge Swivel Bend and Swivel Elbow: Swivel bends and swivel elbows can be supplied with a ball connection instead of bearing assembly Lower bend pipe of the swivel bend can be supplied with an additional support Instead of flanges the elbow bends can be supplied with quick connect or without any flange for welding on the pipe end The swivel bend can be supplied with ball joint or rubber hose combination
