Temperature calibrator LPC 300

pressurevoltagecurrent

Accurate, high resolution, compact, rigid Pressure ranges from 0...250 mbar to 0...6000 bar, as well as vacuum, compound and absolute ranges Changeable reference pressure sensors LR-Cal LPC-S All standard pressure units (plus one self-definable) Conversion pressure to volt/milliamps and vice versa Stores calibration data (plus time stamp from integrated real time clock) Pressure switch test function Menu-driven operating in several languags (English, Italian, French, Spanish, German) Large illuminated colour display Lithium-Ion battery powered Power supply 24 VDC output for pressure transmitters USB- and RS232-interface Calibration certificate, traceable to national standard included in scope of standard delivery (for pressure, current and voltage) The reference pressure sensors LR-Cal LPC-S are equipped with a welded stainless steel membrane, they are suitable for aggressive media, which do not destroy stainless steel 1.4571. The LR-Cal LPC 300 features a complete numeric keypad and cursor block, for easy and simple entering of data. Settable basic parameters: Several basic parameters can be entered into the LR-Cal LPC 300, e.g. ambient temperature, fluid level difference between reference and unit under test, Language (English/French/Italian/Spanish/German), Setting of the realtime clock, Setting of the display, Setting of the powersafe function, Indicating battery level, Tara value (offset), Indicating Min/Max values, Setting/indicating alarm values, Digital software filter, USB- andRS232 settings. The electronic pressure calibrator (documenting process calibrator) LR-Cal LPC 300 can be operated in three different modes:
