Electric valve actuator DCL-MZZ

multi-turnsmall

Multi-Turn Electric Actuator 24VDC with subminiature volune and super torque 18Nm, for pipe and valve Product specification Power: - DC24V Speed: - 2r/min Ambient Temperature: - -25℃~+75℃ Material Of Seal Surface: - Soft Sealed Time/Torque: - 15S/18Nm Protection Class: - IP67 Medium: - Gas/Oil/Water/Other Connection Form: - Flange DCL-02 Multi-turn 24VDC Electric actuator is a new type actuator developed by DCL. Technique Parameters: 1. Electric level, pulse control signal 2. Full-open , Full close postion output signal. 3. Voltage: DC24V±15% 4. Current: 1.1A 5. Output torque: 18Nm 6. Temperature: -25~75℃ 7. Enviroment Humidity:≤95%RH Specification: Type - DCL-MZZ Power - DC24V Motor Power - 20W Rated Current - 1.1A Standard Time/Torque - 18Nm Optional Time/Torque - ╲ Turning Angle - 3r Total Weight - 1.2Kg Insulating Resistance - 100MΩ/250VDC Withstand Voltage Class - 500VAC 1minute Protection Class - IP67 Installation Angle - 360°at any angle Electric Interface - 7-core cable for connection Ambient Temperature - -25℃~+55℃ Fuse - 2A Company profile Dynamic Corporation Limited is a stock holding/high-tech enterprise with self-support export authority, which is engaged in research, development, manufacture and sale for electric actuator, electric valve and its automatic control system. The main leading product, DCL series electric actuator is featuring the compact construction, exquisite appearance, smart control, remarkable performance, superior quality, easy operation and so on.
