Operating mass (incl. Cab) - kg
Module mass (front/rear) - 3900 kg/ 3500 kg
Traction
Speed range - 0-7.5 km/h
Tyre size (12 ply) - 420-70B24
Max. theoretical gradeability - 40 %
Vertical oscillation - ±9°
Number of pads - 132
Pad area - 84 cm2
Compaction
Static linear load - 23.9 kg/cm
Nominal amplitude (high/low) - 1.7 mm/ 0.9 mm
Vibration frequency (high/low amplitude) - 31 Hz/ 43 Hz
Centrifugal force (high/low amplitude) - 181 kN/ 174 kN
Engine
Manufacturer/Model - Cummins QSB 3.3 Tier 3
Type - 4 cylindre Water cooled turbo diesel
Fuel tank capacity - 225 l
Hydraulic system
Driving - Axial piston pump with variable displacement
Axial piston motor with constant displacement.
Radial piston motor with constant displacement (D, PD).
Vibration - Axial piston pump with variable displacement.
Axial piston motor (2) with variable displacement.
Steering - Gear pump with constant displacem.
Service brake - Hydrostatic in forward and reverse lever.
Parking/ Emergency brake - Failsafe multidisc brake in rear axle.
