e-CAM131_iMX8 - Auto Focus Camera for i.MX8 Quad Max e-CAM131_iMX8 is a 13MP auto focus color camera, a perfect imaging companion for iMX8 Quad Max. The e-CAM131_iMX8 camera is interfaced directly to the MIPI CSI-2 interface on the Toradex's Ixora carrier board for Apalis iMX8QM SOM. This camera is based on our popular 13MP camera module, e-CAM130_MI1335_MODwhich has 1/3.2" AR1335 CMOS Image sensor from ON Semiconductor® and a built-in Image Signal Processor (ISP). Key Features of iMX8 Camera: > - Houses e-CAM130_MI1335_MOD - 13MP auto focus MIPI Camera Module > - Plugs directly in to the Toradex's Ixora carrier for Apalis iMXSQM SOM > - High speed 4-lane MIPI CSI-2 interface to connect with the iMXSQM > - Output Format - UYVY > - Operating Température Range : -30® to 70° C > - Board Size (Lx W) - 30 mm x 30 mm > - Lightweight, versatile, and portable two-board solution > - RoHS compliant
