Centrifugal pump DDP550

waterelectricindustrial

Application Aquatec membrane pumps are extremely low-noise and low-vibration and have been developed and produced since 1987 by Aquatec, the leading manufacturer in this sector. They are suitable for use in all kinds of areas of application in agriculture, water purification, medical technology, cleaning technology and air-conditioning technology. Description The DDP550 transfer pump is supplied as standard with an integrated and adjustable pressure switch. If a valve or tap is opened, the pump starts automatically; conversely, the pump stops when the preset pressure is reached. Technical data Max. delivery volume (l/h) - 400-1200 Differential pressure (bar) - 4 Viscosity range approx. (cSt.) from - 1 Viscosity range approx. (cSt.) to - 100 Min. filtration (µm) - 100 Ambient temperature approx. (°C) - 0-50 Medium temperature approx. (°C) - 75 Diameter of connections (mm) - "Quick Disconnect" connections or ½ NPT Material in contact with medium - PA, EPDM, Santopren (further combinations on demand) Total length (mm) - 240 (depending on version) Total length (mm) - 240 (depending on version) Weight approx. (gr.) - 2900 Available voltages (V) - 12, 24, 110, 230 Special voltages - on demand Electrical connection - cable connection
