Plug valve HEXA seriesmanualthreadedEPDM
Add to favorites
Compare this product
Characteristics
- Type
- plug
- Operation
- manual
- Body
- threaded, EPDM
- Applications
- heating, industrial, air conditioning, sanitary
- Other characteristics
- standard
- DN
Min.: 29 mm
(1.142 in)Max.: 155 mm
(6.102 in)- Pressure
8 bar, 18 bar, 25 bar
(116 psi, 261.1 psi, 362.6 psi)- Temperature
Min.: -5 °C
(23 °F)Max.: 110 °C
(230 °F)
Description
TECHNICAL FEATURES:
Temperature limits:
for fluids from –5°C to +110°C
(in absence of steam)
Pressure limits:
See tech. datasheet
Minimal opening’s pressure: 0,02 bar
SPECIFIC FEATURES:
• Limited Headlosses, see Diagram
• Full bore
• Noiseless
• Heavy duty and long endurance
• High resistance
• Ideal tightness at low and high pressure
• Max glycol admitted in water 50%
Application fields:
It is ideal to be used in water systems (sanitary,industrial and agricultural), heating and thermic (radiators, boilers, pumps system).
Mountable in all the positions: vertical,horizontal,oblique.
Follow the fluid’s direction indicated with an arrow
Threaded end connections:
• Standard female according to UNI ISO 228/1.
Special executions:
• EPDM seal.
All the valves comply with the regulation 97/23/CE and are tested 100% on pneumatic seal with electronic control.
