Ball valve SUN WP seriespneumatically-operatedmanualfor compressed air
Add to favorites
Compare this product
Characteristics
- Type
- ball
- Operation
- pneumatically-operated, manual
- Media
- for compressed air
- Other characteristics
- with actuator, single-acting, double-acting
- DN
Max.: 2 in
Min.: 0.375 in
- Temperature
Max.: 150 °C
(302 °F)Min.: -20 °C
(-4 °F)
Description
ACTUATOR FEATURES:
• ROTATION ANGLE: 90°.
• TEMPERATURE LIMITS: -20°C / +90°C.
• MAXIMUM SUPPLY PRESSURE: 10 bar (8 bar for DNA045).
• NOMINAL PRESSURE: 5.62 bar.
• SUPPLY FLUID: filtered compressed air.
• LUBRICATION: NBR compatible oil to be used.
For further information on the actuator technical features refer to the specific data sheet for actuator at the end of this catalogue (page 348/349).
STANDARD VALVE FEATURES:
• TEMPERATURE LIMITS: –20°C / + 150°C (PTFE).
• MAXIMUM WORKING PRESSURE: Please refer to manual valve.
• CONNECTIONS: F/F Rp UNI ISO 7/1 (UNI EN 10226)
DIN2999 parallel
M/F (male R UNI ISO 7/1 (UNI EN 10226, female parallel).
• MOUNTING PLATE: ISO 5211.
For general applications and special executions, see the manual valve.
