Control terminal with keyboard 1338-20

wall-mountfor controlmonitoring

To control electric locking elements along escape routes; certified in compliance with EltVTR Escape door control module Emergency button lights up; features reusable, shatterproof protective cover Integrated door status indicator (green / red / yellow) signalling unlocked / locked / alarm status Sign emergency button alarm signal and tampering contact; Key switch to control door With Euro profile half cylinder, including 3 keys Adjustable time intervals for temporary release, pre-alarm, alarm interval Monitoring of time door is open during temporary release. Connections: screw terminals Scope of delivery 1 control terminal 1 emergency button sign 1 profile-half cylinder 1 operating manual Technical data Rated voltage - 230 VAC Output voltage - 24 V DC SELV Output current - for external consumers: 0.45 A *Nicht Übersetzt: Eigenstromaufnahme - 0,155 A Control - Yes, integrated Power supply - Yes, integrated Connection to panel, visualisation system, OPC server - Yes, Configured centrally using FT Manager - No Stand-alone operation with I/O module - No Stand-alone operation (offline) - Yes Emergency switch - Yes Control element - Key switch with Euro profile cylinder; cam position 8 x 45°; 30.5 mm long Setting of times and functions - Via DIP switches Operating temperature range - 0 °C to +40 °C Class of protection - IP 20 Dimension - (HxWxD) 249x92x98 mm Inputs - E1: temporary release; E2: fire alarm system; E3: timer Outputs - A1: locked/unlocked; A2: Collective alarm, contacts 24 V / 1 A Key switch on opposite side to direction of escape - Yes Escape door terminal with bi-directional escape route - No
