Accelerator pedal Metis
controlHall effectsingle pedal

Accelerator pedal - Metis - ELEN Srl - control / Hall effect / single pedal
Accelerator pedal - Metis - ELEN Srl - control / Hall effect / single pedal
Accelerator pedal - Metis - ELEN Srl - control / Hall effect / single pedal - image - 2
Add to favorites
Compare this product


Characteristics

Function
control, accelerator
Technology
Hall effect
Type
single pedal
Other characteristics
rugged
Applications
for vehicles

Description

The Elen Metis series throttle accelerators are controls designed for all electrically powered work vehicles with a steering wheel, in particular for vehicles used for moving and lifting loads and for professional cleaning. The Hall-effect operating principle, the firmware for managing the signal and trigger thresholds and the innovative magnetic return system make the mechanics extremely simple and reliable (reducing the presence of contact parts to the essential) and the signal precise, repeatable and programmable. These features, combined with the resin coating and sealed housing, make the product suitable for use in harsh environments. The principle of operation is that a Hall sensor intercepts the field of the magnet integrated with the lever pin and provides an output signal that is linear and proportional to the angle of rotation. VERSATILITY Supply voltage: 5 V; 10-30 V; 12-48V; Programmable analog output (standard voltage 0-5V; 0-10V): min-max levels within the supply voltage range; increasing or decreasing inclination angle; IVS single (windowed) or double; NO or NC; changeover point can be programmed on a value of choice Output signal: single or double Customizable shaft length Customizable cable and connector RELIABILITY Contactless Hall-effect Output and IVS managed by the firmware, without contact switches or manual calibrations contatto né calibrazioni manuali Protection class IP67 Infinite life cycle thanks to the magnetic return system Reversed polarity protection to ensure that no damages occur to the throttle if connected incorrectly. Does not require calibration nor maintenance
