24 Vdc electromechanical relay SIF21212 Vdc110VDC48VDC
Add to favorites
Compare this product
Characteristics
- Control voltage
- 24 Vdc, 12 Vdc, 110VDC, 48VDC, 5 VDC, 60VDC
- Contact configuration
- 2 NO/NC
- Mounting
- for printed circuit boards
- Function
- power, interface
- Terminal strip
- weld-on
- Other characteristics
- with guided contacts, IEC
- Switching current
Min.: 3 mA
Max.: 10,000 mA
Description
The 3-pole relay of the SIF 3 series with forcibly guided contacts according to IEC 61810-3 in an extremely flat design (10.9 mm), which is characterized by its wide switching current range. In addition, components can be fitted under the relay.
Switching current: 3mA - 10A
Nominal coil power: 600mW
Test voltage (rms): 4000V
The following product variants are available in the ELESTA shop:
• Coil Voltage: 12 VDC
• Coil Voltage: 24 VDC
