24 Vdc electromechanical relay SIM22212 Vdccompactfor printed circuit boards
Add to favorites
Compare this product
Characteristics
- Control voltage
- 24 Vdc, 12 Vdc
- Features
- compact
- Mounting
- for printed circuit boards
- Other characteristics
- with guided contacts, IEC
- Switching current
Min.: 10 mA
Max.: 8,000 mA
Description
The SIM 222 is a compact four-pole relay with forcibly guided contacts to IEC 61810-3 with overmolded coil design and is therefore also suitable for applications in the ATEX area. Crown contacts provide a high switching reliability. It has extremely high air and creepage distances.
Switching current: 10mA - 8A
Nominal coil power: 1000mW
Test voltage (rms): 4000V
The following product variants are available in the ELESTA shop:
• Coil Voltage: 12 VDC
• Coil Voltage: 24 VDC
