Manual positioner MDE187

linear6-axisXYZ

• Based on ultra-stable patented† design XYZ flexure stage • 2 mm linear travel in XYZ axes with 20 nm resolution • Roll adjustable through full 360° rotation • Roll resolution 5 arc seconds • Optical axis height 125 mm • Slotted design for easy insertion and removal of fibre • V-block preset on axis with less than 1 µm concentricity error • V-block can be re-centred by user • Pitch and yaw resolution < 0.1 arc secs • Pitch and yaw adjustments about a single point in space in a true arc with no cross-talk The model MDE187, six-axis positioner is built up from the Elliot Gold™ Series of micro-positioning precision components. It facilitates precise 6D manual adjustment of a fibre's position in XYZ linear axes, plus pitch (θY), yaw (θZ) and roll (θX) with excellent accuracy and long term stability. The Six-Axis positioner comprises: • MDE185 Pitch and Yaw Stage (High Precision Adjusters) • MDE717 High Precision Fibre Rotator • MDE154 Clamp Set • MDE122 Elliot Gold™ Series XYZ Flexure Stage (High Precision Adjusters)
