Powder coating line

Powder coating lines, which are consist of pretreatment, drying oven, powder coating booth and curing ovens, are designed depending on the needs of customers. Powder coating lines are used to coat metal materials by powder paint. The materials placed on the conveyor line are first passed through the surface treatment washing line to be cleaned from oil, dirt, and rust. This line is designed to be used for iron phosphate, zinc phosphate, nanotechnology or only lubrication chemicals according to the quality expectation. Prepared materials in the surface treatment facility, are dried in the drying oven and made ready for powder coating application. The parts entering the powder coating booth on the conveyor line are painted by a robot or manual powder coating gun. Afterward, they are transferred to the oven which has set for necessary heat and time for powder curing. After the curing process is completed, the parts are discharged from the conveyor in the discharge section after cooling. 1. Loading Area: It is the section where the parts coming from the welding line are loaded on the conveyor line for painting. 2. Chemical Cleaning Line: The parts coming from the loading line enter the washing line, which is the first process, the washing line is sorted as lubrication, rinsing, iron phosphate, rinsing, rinsing in this example project. 3. Drying Oven: The parts washed in the chemical cleaning line enter the drying oven, the oven temperature is set between 100°C and 120°C, the part surface is made completely dry for the powder coating process.
