8-I input module IC694MDL632DIN railpanel
Add to favorites
Compare this product
Characteristics
- Number of inputs/outputs
- 8-I
- Mounting
- DIN rail, panel
Description
RX3i IO is designed for mission critical discrete and process applications. The rack-based IO offers advanced diagnostics and outstanding flexibility, with a wide range of standard and advanced IO.
Features
High-speed and patented technology for faster throughput
Hot swap capability
A variety of voltage ranges, types, current capacity, isolation and response time to meet your application needs.
Specifications
Input Count, Type & Speed8 Point; Pos/Neg Logic; 7mS On/7mS Off
Supply Voltage and On/Off Voltage125VDC; Range 110~150VDC; On >90
Backplane Current Consumption40mA @ 5VDC
Approvals & Standards Ordinary LocationsUL 508, equivalent to CSA C22.2 No 142M1987 standard
Approvals & Standards Hazardous LocationsClass I, Div. 2, Groups A, B, C, D
Mounting FormatOn Panel/DIN Rail
