PCI interface card

CAN

Description CPC-PCI is a passive CAN plug-in board for PCI slots. CPC-PCI was designed for industrial series application and has a robust and cost efficient construction. CPC-PCI supports either one, two or four CAN channels that can be operated independently with different data rates. The interface comes with the NXP CAN controller SJA1000, that offers good diagnostic attributes. CPC-PCI maps the CAN controller(s) directly in the address space of the PC and allows access of the CAN messages with low latencies. Existing software for the supported CAN controller can easily be adapted. The CAN communication with CPC-PCI may be handled either in interrupt controlled mode or in polled mode, interrupt channels are assigned automatically (Plug & Play). Optionally, CPC-PCI is available with galvanic separation between PC and CAN bus. A galvanic separation between the CAN channels is also possible by separate DC/DC converters. Special Features CAN Plug-In Board CPC-PCI Passive CAN Interface for PCI slots One, two or four CAN channels with Controller NXP SJA1000 Optional galvanic separation of CAN controller to PC Optional galvanic separation between CAN channels Supports 11 bit frames and 29 bit frames Development kits for Windows 2000/XP/Vista/7/8 and Linux available
