NXP i.MX7 computer-on-module emSTAMP-Neon-CM7

ARMUSB 2.0Ethernet

Do you have growing requirements in the areas of real-time capabilities and energy efficiency? The emSTAMP-Neon-CM7 module addresses these requirements! The STM32 family is part of the ST longevity program. It is usually renewed every year and offers a timely discontinuation announcement directly from the manufacturer ST Microelectronics. The manufacturer guarantees a product availability of 10 years. The module relies on ST's software ecosystem (STM32CubeMX, System Workbench for STM32 SW4STM32). Choose the developer kit with or without display for a quick start into your application development. Key features: Microcontroller STM32F769NI from ST Single-core 32-bit ARM Cortex-M7 Up to 216 MHz clock speed 1-2 MByte of internal Flash 512 KByte of internal SRAM high energy efficiency double precision Floating point unit (FPU -64 Bit) Interfaces: Ethernet 10/100Mbit (LAN8720), CAN, SPI, I2C, DAC, ADC, RGB18 LCD, USB 2.0 Host, MicroSD, JTAG, UART, RTC, SDIO, 6x GPIO, SAI (Serial Audio Interface) industrial module (COM/SOM), also available in extended temperature range 32MB SDRAM and 16MB QSPI NOR Flash scalable and long-term available IoT capable Size 28mm x 28mm
