Optical data cable 6917D series

high-temperaturetwisted pairfor accelerometers

Low noise, twisted pair cable assembly, Teflon Jacket, 7/16-27 (2 pin socket) to pigtail, Viton Boot, 10 feet Key features • For use with differential high impedance output piezoelectric accelerometers • Critical parameters 100%tested • Continuous use up to 550°F (288° C), intermittent 660°F (315°C) • Ideal for use in engine test cells Description The 6917D is a low-noise cable assembly consisting of a twisted pair of low-noise treated Teflon wires and an outer shield. The rugged plug features a specially designed assembly with high force contacts and alumina inserts for high temperature operation. A molded Viton splash-proof boot protects the connector from moisture, oil and other contaminants. The opposite end of the cable is terminated in pigtails. The stranded wire is tinned and the lownoise treatment is removed at the cable’s end for user convenience. This cable is typically used in turbofan environments at temperatures up to 550°F (288°C).
