Vertical freezer

for razor bladesfor heat treatment

Sub Zero Chamber. Vertical Sub-Zero Chambers for heat treatment applications of automotive components. Strip - Cooled Deep Freezer for Sub-Zero Treatment of Razor Blades. Deep Freezer for Razor Blades designed for sub-zero process of razor blades coming out of furnace. It works on conduction principle of heat transfer method to cool the heated strip by sub-zero process •ESC-Series Strip cooler – Deep freezer is designed with uncompromised features included in the system to meet the changing application needs of simulation of deep temperatures upto -80°C for sub-zero process applications of razor blades coming out from the freezer. •Product is inbuilt with robust cascade water cooled refrigeration system with highly efficient BPHE for Water cooled condenser and Cascade heat exchanger. •Evaporator heat exchanger is designed with two layers of Solid aluminum block over with blade passing brass plate for conduction cool passing. •Deep freezer is designed with conduction heat transfer method to cool the heated strip for sub-zero process. CONSTRUCTION FEATURES •Condition section is made with solid block Aluminium heat exchanger via conduction method. •Over the heat exchanger Brass slatted plate with dead weight will be Easy to access conditioning for maintenance. •On the brass sheet 2 or 4 numbers of 50x15mm slots will be provided for passing the strips. •Over the conditioning section insulated door will be provided.
