Hydraulic rolling machine SW 1200 S5

High-strength, welded construction Hydraulic pressurizing system with pressure presetting function Externally mounted rollers, permitting monitoring of the rolling process High-strength sawblade mounting assembly with spindle drive by gear motor for advancing and reversing movements Hydraulic motor shuts down on completion of rolling process, thus preventing unnecessary heating of the hydraulic fluid Rollers do not begin to turn until sufficient rolling pressure has built up The machine is started by a touch switch and can be stopped at any time and in any position Technical data - SW 1200 S5 Max. saw dia.: - 1200 mm Max. rolling circle dia.: - 1080 mm Min. rolling circle dia.: - 160 mm Roller protection - from machine: - 500 mm Max. rolling pressure: - approx. 10 to. Rolling speed: - by potentiometer adjustable Drive power, roller drive: - 2,2 kW Drive power, hydraulic motor: - 2,2 kW Drive power diameter adjustment: - 0,37 kW Operating voltage: - 230/400 V, 50 cycles Cable cross section: - 5 x 2,5 mm² Dimensions: - Length: 2220 mm Depth: 1310 mm Height: 1710 mm Weight: - 985 Kg
