Needle valve RKVregulatingfor water
Add to favorites
Compare this product
Characteristics
- Type
- needle
- Function
- regulating
- Media
- for water
- DN
Max.: 2,000 mm
(78.74 in)Min.: 350 mm
(13.78 in)- Pressure
Max.: 100 bar
(1,450.4 psi)Min.: 10 bar
(145 psi)
Description
DN 350 - 2000
PN 10 - 100
Body: EN-JS1030
Coating: Epoxy, Special coatings
Proven technology in flexible, multi-component design for larger nominal widths
Designed at one Piece
Safe energy conversion through constant annular cross-section
Change in cross-section through axially movable internal piston
Flexible regulatting inserts depending on application
Available as sonstricted version (RKVE) for special installation situations
Also suitable as valves for air regulation in aeration tanks in sewage treatment plants
Catalogs
applications_irrigation
8 Pages
