Water rotary joint 400A series
for hot oilfor steamfor chemicals

Water rotary joint - 400A series - esz makina - for hot oil / for steam / for chemicals
Water rotary joint - 400A series - esz makina - for hot oil / for steam / for chemicals
Water rotary joint - 400A series - esz makina - for hot oil / for steam / for chemicals - image - 2
Water rotary joint - 400A series - esz makina - for hot oil / for steam / for chemicals - image - 3
Water rotary joint - 400A series - esz makina - for hot oil / for steam / for chemicals - image - 4
Water rotary joint - 400A series - esz makina - for hot oil / for steam / for chemicals - image - 5
Add to favorites
Compare this product


Characteristics

Medium
for water, for hot oil, for steam, for chemicals
Number of passages
multi-passage
Material
stainless steel
Other characteristics
radial, screw-in, ball bearing, dual-flow, single flow
Rotational speed

Max.: 3,500 rpm
(21,991.15 rad.min-1)

Min.: 0 rpm
(0 rad.min-1)

Pressure

Max.: 50 bar
(725 psi)

Min.: 0 bar
(0 psi)

Nominal size

Max.: 50 mm
(1.969 in)

Min.: 8 mm
(0.315 in)

Description

ALL IN STAINLESS STEEL For GENERAL PURPOSES, WATER, CHEMICALS 1/4" (DN08) - 2” (DN50) - Single and dual fl ow design - Self supported rotating joint - Radial housing connection - Balanced mechanical seals - Easy and quick replacement of mechanical seals - Vent holes on housing Special Options - Threaded vent holes with plugs Application Parameters Max. Pressure : 50 bar 750psi Max. Temperature : 160°C 320 °F Max. Speed (1/4” - 3/4”) : 3500 RPM 3500 min-1 (1") : 3000 RPM 3000 min-1 (1 1/4” - 1 1/2”) : 2500 RPM 2500 min-1 (2”) : 750 RPM 750 min-1 Avoid working with max. speed at max. pressure
