Water rotary joint 800 series
multi-passagehydraulicaluminum

Water rotary joint - 800 series - esz makina - multi-passage / hydraulic / aluminum
Water rotary joint - 800 series - esz makina - multi-passage / hydraulic / aluminum
Water rotary joint - 800 series - esz makina - multi-passage / hydraulic / aluminum - image - 2
Water rotary joint - 800 series - esz makina - multi-passage / hydraulic / aluminum - image - 3
Water rotary joint - 800 series - esz makina - multi-passage / hydraulic / aluminum - image - 4
Add to favorites
Compare this product


Characteristics

Medium
for water
Number of passages
multi-passage
Applications
hydraulic
Material
aluminum, stainless steel
Other characteristics
radial, single flow
Rotational speed

Max.: 10,000 rpm
(62,831.85 rad.min-1)

Min.: 0 rpm
(0 rad.min-1)

Pressure

Max.: 70 bar
(1,015 psi)

Min.: 0 bar
(0 psi)

Nominal size

Max.: 10 mm
(0.394 in)

Min.: 8 mm
(0.315 in)

Description

For COOLANT, WATER 1/4" (DN08) - 3/8" (DN10) - Single fl ow - Self supported rotating joint - Stainless steel shaft - Aluminium housing - Radial/axial connection - Vent holes on housing - Slingers for bearing protection - Full fl ow - Balanced silicon carbide mechanical seals - Tuc seals as option Application Parameters Max. Water Pressure : 70 bar 1000psi Max. Speed : 10.000 RPM 10.000 min-1 Max. Temperature : 120°C 250°F Avoid working with max. speed at max. pressure
