Lifecycle management software SEE Cabling

designfor cables

SEE Cabling helps design the detailed cabling for a complex installation starting for the installation synoptic. Inputs Equipment Devices & Cables installation from SEE Systems Design (Cabling Diagrams) or other synoptic design tool. Equipment Devices & Cables definition from SEE EED Catalogue Outputs Description of cables extremities Connection of wires on terminals or pins Shielding Description (several methods are proposed) Shunt management: on the same terminal device or from different connectors. Signal management: Tracing from transmitter to receivers Accessories management for all devices Functionalities Manual Cabling of a wire on a pin Automatic Cabling (for extremities or for Equipment Devices) from a catalog of standards. Live Cycle management for cables extremities Export of cabling reports on Excel or PDF Global Update: Ex. Switching P/N for a project
