Electrical design software SEE Electrical 3D Shop floor

schematic drawing3D

Mounting validation helps follow team work and  ensures time saving as well as consistency in panels series assembly Features Touch-screen compatible and barcode readers support Clear view on devices which need to be  mounted and on their position Wire list provides clear information on involved  devices and route to take Selected devices are highlighted and user can  validate the mounting with a finger touch User can select wire in the list with mouse, finger or  even by flashing barcodes engraved on wires Filters are available to organise work according to  preferences Possible to filter by device, color, wire size, etc. Drawing can be explored with finger or mouse to have a clear  view on the work to do
