Diaphragm pump MultiFlow 35 MAacidsolenoid-drivenstationary
Add to favorites
Compare this product
Characteristics
- Technology
- diaphragm
- Fluid
- acid
- Operation
- solenoid-driven
- Mobility
- stationary
- Domain
- industrial
- Applications
- adjustment
- Material
- PTFE, plastic, PP, ceramic, PVDF
- Protection level
- IP65
- Other characteristics
- standard, adjustable, flow, wall
- Flow
Max.: 35 l/h
(9.24602 us gal/h)Min.: 4 l/h
(1.05669 us gal/h)- Pressure
Max.: 10 bar
(145.038 psi)Min.: 0 bar
(0 psi)- Weight
2.9 kg
(6.39 lb)
Description
The MultiFlow-35 MA is an electromagnetic pump with constant flow rate, manually adjustable via a potentiometer. The model (max flow rate/working pressure) can be selected by the user.
Manual adjustment of flow rate
Regulation range: 0-100%
Level probe input
Acid resistant plastic box
IP65 protetction degree
Wall or horizontal basement mounting
Standard pump head: in PP or PVDF, diaphragm in PTFE, seats in FPM, ceramic ball valves*
CE certification
Models selectable from the user
further configurations available on request
