Electro-pneumatic transducer 40701

Learning objectives of pneumatics: Operating of pneumatic components Determination of components for the solution of different pneumatic controls Assembly of pneumatic components with subsequent functional controls Planning, installation, commissioning and maintenance of pneumatic control systems Creation of pneumatic circuit diagrams and logic diagrams Development of test criteria for functional testing analysis and determination of errors The application mask are placed on the Pneumatic Applications Board. As a result, the non-task-related component slots are covered, the task-related remain free and provided with circuit symbols. The application masks are photorealistic with 3D graphics design to promote a sustainable understanding and to ensure application-related processing of the work order.
