Single-pole switch NQ02VZ-5000
reinforcedIECIP67

Single-pole switch - NQ02VZ-5000 - EUCHNER GmbH + Co. KG - reinforced / IEC / IP67

Single-pole switch - NQ02VZ-5000 - EUCHNER GmbH + Co. KG - reinforced / IEC / IP67

Add to favorites

Compare this product

Go to the EUCHNER GmbH + Co. KG website for more information

Characteristics

Number of poles

single-pole

Protection level

reinforced, IEC, IP67

Other characteristics

thermoplastic, latching, with silver contacts, with housing, without guard, safety, electromechanical

Primary current

0.27 A, 0.75 A

Voltage

250 V

Operating temperature

Min.: -25 °C
(-13 °F)

Max.: 70 °C
(158 °F)

Description

• Compact housing • Any installation orientation • Connecting cable, 5m If guard locking is not needed, there is now an even smaller solution. The safety switch NQ without guard locking impresses with its dimensions of 30 x 15 x 78 mm. Three switching contacts are integrated into the NQ. With the series NQ, perfectly adapted safety products are available particularly for very small machines, as are common for instance in packaging systems.

VIDEO

Catalogs

Safety Switches NQ/TQ

Safety Switches NQ/TQ

6 Pages
