Lever switch CES-AP-C01-AH-SB-111145

single-poleIP67electromechanical

• No series connection • Short circuit monitoring • 2 safety outputs (semiconductor outputs) • Category 4 / PL e according to EN ISO 13849-1 • M12 plug connector 5-pin; pin 5 not used • Unicode Approach direction Can be adjusted in 90° steps Short circuit monitoring The switch generates its own clock signal on the output lines OA/OB. Pay attention to this aspect when connecting to control systems and relays. Unicode evaluation Each actuator is highly coded (unicode). The switch detects only taught-in actuators. Additional actuators can be taught-in. Only the last actuator taught-in is detected. Category according to EN 13849-1 Due to two redundantly designed semiconductor outputs (safety outputs) with internal monitoring suitable for: Category 4/PL e according to EN 13849-1 Important: To achieve the stated category in accordance with EN ISO 13849-1, both safety outputs (OA and OB) must be evaluated. LED indicator STATE Status LED DIA Diagnostics LED
