Single chamber industrial cleaning machine for hydraulic cylinders
CLEANING MACHINE FOR MEDIUM-SMALL HYDRAULIC CYLINDERS
Cleaning technology with water and water-based detergents. Cleaning chamber with usable volume of 1150 litres and a 2000 kg payload
APPLICATION SECTORS
cleaning of medium and small size hydraulic cylinders
The machine is made of AISI 304 stainless steel (EN 1.4301) throughout. The single chamber machine features very compact dimensions. TermoVide® V1700/1 heralds a new generation of industrial cleaning machines. The cleaning machine uses water-based detergents. The cleaning process takes place in a single hermetically sealed tank: the single chamber. The TermoVide® V1700-1 single chamber machine is designed to clean small and medium-size hydraulic cylinders. The cleaning process uses a single water-based detergent but the machine is configured for the use of two detergents in order to deal with different types of contaminants. The single chamber has useful dimensions of 800W x 1200D x 1200H mm, a working volume of 1150 litres, and a 2000 kg payload. Phases available in the cleaning process:
VCA Vacuum and controlled atmosphere
insR-uDi/T initial spray rinse, non-recirculated recycled demineralized water or mains water
insR-r-uDi/T initial spray rinse, recirculated recycled demineralized water or mains water
sW-De1 Spray cleaning, detergent 1
sR-uDi/T spray rinse, non-recirculated recycled demineralized water
sR-r-uDi/T spray rinse, recirculated recycled demineralized water
sW-De2 Spray cleaning, detergent 2
sR-uDi/T spray rinse, non-recirculated recycled demineralized water
sR-r-uDi/T spray rinse, recirculated recycled demineralized water
